TEMPORARY ROOFTOP SAFETY PRODUCTS
For Rent or Purchase
Perimeter Clamps
Manufacturer: Garlock Safety
Meets OSHA Requirement 1926.502(b)
Alternate Product Views
FEATURES
OSHA compliant perimeter edge protection
Versatile as it can be used for parapet walls or flat surfaces
Allows 100% unfettered access all the way to the very edge of the roof
Adjustable stanchions ensure rails are at the correct height per OSHA requirements
Safety assured with Jobsite provided 2” X 4” lumber for the rails
Versatile as it can be used for parapet walls or flat surfaces
Allows 100% unfettered access all the way to the very edge of the roof
Adjustable stanchions ensure rails are at the correct height per OSHA requirements
Safety assured with Jobsite provided 2” X 4” lumber for the rails
SPECIFICATIONS
Attachment type - Non-penetrating clamp or screw down
Clamping range - 8” to 24”
Clamp material - Steel
Clamp finish - Zinc plated
Clamp weight - 14 lbs.
Stanchion height - Adjustable to achieve OSHA required 42” height
Mid-rail height - 20” when the top rail is at 42”
Rail material - User-provided 2” X 4” lumber
Stanchion material - Steel
Stanchion finish - Powder-coated safety yellow
Due to continuous improvement, specifications are subject to change without notice.
